The Pleiades or M45 (part of) (Ian A Smith). Skywatcher 200p on NEQ6 mount, with guiding and dithering every 10 images. Optolong CLS-CCD filter, Baader MPCC M3. ASI294MC Pro at -20C. 67 x 60 second exposures (1 hour 7 minutes) at Gain 121, Offset 30 , 20 dark frames, 30 flat fields, 30 dark flat frames. Processed in APP, Topaz de-noise and Photoshop. The main stars are over exposed and it was a bit windy. 13th November 2020

The Pleiades or M45 (part of) (Ian A Smith).
Skywatcher 200p on NEQ6 mount, with guiding and dithering every 10 images.
Optolong CLS-CCD filter, Baader MPCC M3. ASI294MC Pro at -20C. 67 x 60 second exposures (1 hour 7 minutes) at Gain 121, Offset 30 , 20 dark frames, 30 flat fields, 30 dark flat frames.
Processed in APP, Topaz de-noise and Photoshop.
The main stars are over exposed and it was a bit windy. 13th November 2020

M45 (Pat Devine) M45 also known as the Pleiades or the Seven Sisters from last night. M45 is an open star cluster and lies about 400 light years away located in the constellation of Taurus. The cluster contains 500 stars over a sphere that is 14 light years wide. The cluster is moving at a different radial velocity from the nebulosity suggesting the stars are crossing the path of dust in a molecular cloud. The stars in the Pleiades cluster formed in the last 100 million years and contains a number of hot, blue, extremely luminous B-type stars and is one of the nearest star clusters to Earth. October 31st 01:49 AM Edinburgh Bortle 8 zone Celestron RASA 8" ZWO 183mc pro Optolong lpro filter

M45 (Pat Devine)
M45 also known as the Pleiades or the Seven Sisters from last night. M45 is an open star cluster and lies about 400 light years away located in the constellation of Taurus. The cluster contains 500 stars over a sphere that is 14 light years wide. The cluster is moving at a different radial velocity from the nebulosity suggesting the stars are crossing the path of dust in a molecular cloud. The stars in the Pleiades cluster formed in the last 100 million years and contains a number of hot, blue, extremely luminous B-type stars and is one of the nearest star clusters to Earth.
October 31st 01:49 AM
Edinburgh Bortle 8 zone
Celestron RASA 8″
ZWO 183mc pro
Optolong lpro filter
ZWO air pro
ZWO EAF
Sky-Watcher HEQ5 Pro
86 * 30s lights inc flats, darks and bias
Gain 122 at -10C

M45 - The Pleiades (Pat Devine) February 7th 2022 from 19.45 Edinburgh Bortle 7/8 zone Celestron RASA 8" ZWO 183mc pro ZWO EAF Optolong l-pro ZWO air pro Sky-Watcher HEQ5 Pro 300 x10ss lights with flats, darks and bias Gain 122 at -10C Processed in APP , Pixinsight and Photoshop

M45 – The Pleiades (Pat Devine)
February 7th 2022 from 19.45
Edinburgh Bortle 7/8 zone
Celestron RASA 8″
ZWO 183mc pro
ZWO EAF
Optolong l-pro
ZWO air pro
Sky-Watcher HEQ5 Pro
300 x10ss lights with flats, darks and bias
Gain 122 at -10C
Processed in APP , Pixinsight and Photoshop



M45 (William Bonar) Autostack_pleadies_DBE(1)

M45 (William Bonar)
Autostack_pleadies_DBE(1)



M45 (Greig Louden) Redcat 51, ASI 533 MC-Pro IDAS LP filter 2 hours of 120s 3rd Jan 2022 Stacked in APP and processed in PI

M45 (Greig Louden)
Redcat 51, ASI 533 MC-Pro
IDAS LP filter
2 hours of 120s
3rd Jan 2022
Stacked in APP and processed in PI



M45 (William Bonar) 20221103-235444 127ED - 2600MC 22 x 120s

M45 (William Bonar)
20221103-235444
127ED – 2600MC
22 x 120s



M45 Pleiades (Nigel Goodman) 16 x 300s 391g (1 of 1) First time out with the scope for a while. 102 ED, L'Enance, 0.75 reducer, binned 2x2 as an experiment.

M45 Pleiades (Nigel Goodman)
16 x 300s 391g (1 of 1)
First time out with the scope for a while. 102 ED, L’Enance, 0.75 reducer, binned 2×2 as an experiment.



M45 The Pleiades (Pat Devine)

M45 The Pleiades (Pat Devine)
